| Product Model | IF-USB-TYPE-C-1-45-1.5-3A |
| Dielectric Streangth | ≥3000V AC/min |
| Insulation Resistance | 500V DC/2MΩ |
| Insulating Material | Fire Retardant PC |
| Metal Material | Phosphor Brass H62 Brass Nickelplated |
| Current & Voltage | Input 100~240V AC 50~60Hz 5V 2.1A
Output Type-A & Type-C 5V-3A 9V-2A 12V-1.5A |
| Output Capacity | Loaded 18W Max
No-load power consumption 0.1W Max |
| Support Agreement | USB TYPE-C QC3.0 & PD |
| Environmental Requirement | Operation -10℃~+40℃ 20% ~90% RH
Storage -20℃~+85℃ 10% ~95% RH |
| Tolerance Standard | SJ/T 10628-1995 Medium Grade 5 |
| Environmental Protection Standard | ROHS |
