Bar Type Terminal Block IF-7930-D-3-3-75A

Bar Type Terminal Block IF-7930-D-3-3-75A
www.infinitiveway.com

PRODUCT PARAMETERS:

Product   ModelIF-7930-D-3-3-75A
Dielectric   StreangthPower Frequency withstand   Voltage 2500V
    Impulse withstand Voltage 6000V
Insulating   MaterialPC
Metal   MaterialH62 Brass(Sn Coated)
Current   Voltage75A 600VDC Max.
Working   Temperature-40~120℃
Flame   Retardant RatingUL94V-0
Cable   Size22mm²
Screw   Torque18lbf - In
